The DEYE BOS W PACK5.1 is a high-performance 5.12kWh lithium iron phosphate (LiFePO₄) battery module designed for residential and small commercial solar applications. Engineered by Ningbo Deye Inverter Technology Co Ltd, this battery provides exceptional reliability, advanced safety features, and seamless compatibility with Deye hybrid inverters and other leading brands.
Its modular stackable design allows easy scalability for larger systems, making it ideal for off-grid, hybrid, or backup solar installations. With over 6,000 cycles at 90% depth of discharge (DoD), the DEYE BOS W PACK5.1 delivers long-lasting energy security and excellent return on investment.
Usable Energy Capacity: 5.12kWh
Battery Type: Lithium Iron Phosphate (LiFePO₄)
Scalability: Up to 6 units (≈30.7kWh total)
Cycle Life: 6,000+ cycles at 90% DoD
Compatibility: Optimized for Deye hybrid inverters and works with other brands
BMS Protection: Intelligent Battery Management System for safety and performance
Applications: Off-grid, on-grid hybrid, and backup energy systems
Battery Type: Lithium Iron Phosphate (LFP)
Nominal Energy Capacity: 5.12kWh
Nominal Voltage: 51.2V
Continuous Discharge Current: 100A
Peak Discharge Current: 120A (10s)
Cycle Life: >6000 cycles @ 90% DoD
Scalability: Up to 6 units in parallel (30.7kWh total)
Dimensions: 480mm x 442mm x 132mm
Weight: ~50kg
IP Rating: IP65 – suitable for indoor/outdoor installation
Communication Ports: CAN / RS485
Operating Temperature: -20°C to +55°C
Warranty: 10 years
Application Type | Use Case |
---|---|
Residential Backup Storage | Keeps homes powered during grid outages, ensuring uninterrupted supply for appliances. |
Off-Grid Solar Systems | Enables complete energy independence in rural or remote areas. |
Hybrid Solar Systems | Works with on-grid + battery setups for maximum efficiency. |
Commercial Small Storage | Provides backup for small businesses to protect critical loads. |
Scalable Expansion | Stackable units allow flexibility for growing energy demands. |
Step | Description |
---|---|
Site Preparation | Choose a cool, ventilated area. Ensure surface can support 60kg per unit. |
Safety Measures | Wear PPE. Disconnect AC/DC before installation. Follow IEC/UL standards. |
Mounting | Use rack-mount or stack units vertically with brackets provided. |
Clearance | Maintain ≥150mm spacing around each unit for airflow. |
Grounding | Properly ground the system using ≥16mm² copper wire. |
Communication Setup | Connect via CAN/RS485 to compatible inverters (Deye, Victron, GoodWe, etc.). |
Power Connection | Use 25–50mm² DC cables, observing polarity. |
Commissioning | Configure DIP switches for inverter type, activate BMS, and verify status LEDs. |
Testing | Perform charge/discharge test and confirm communication with inverter. |
1 × DEYE BOS W PACK5.1 Battery Module
1 × Communication Cable (CAN/RS485)
1 × Mounting Bracket
1 × Installation Manual (PDF)
1 × User Manual (PDF)
Q1: What is the usable capacity of the DEYE BOS W PACK5.1?
A: The usable capacity is 5.12kWh at 90% DoD.
Q2: How many units can be connected in parallel?
A: Up to 6 units, totaling around 30.7kWh.
Q3: Is it compatible only with Deye inverters?
A: No. While optimized for Deye, it also works with other brands like Victron, GoodWe, and SMA.
Q4: What is the warranty period?
A: 10 years or 6,000+ cycles (whichever comes first).
Q5: Can it be used outdoors?
A: Yes, the IP65 rating allows both indoor and outdoor installation.
Q6: What communication options are available?
A: CAN and RS485, ensuring seamless inverter integration.
Q7: Does it require special cooling?
A: No external cooling required. The battery is designed with natural convection cooling.
