Key Features

• Measurement Range: 0 to 200 ppm (auto-ranging)

• Lower Detectable Limit: < 0.04 ppm (40 ppb)

• Precision: 0.1 ppm or 0.1% of reading, whichever is greater

• Noise: < 0.02 ppm or 0.2% of concentration reading, whichever is greater

• Response Time: 60 seconds to 95%

• Sample Flow Rate: 1.0 L/min

• Operating Temperature: 0 to 40°C

• Power Supply: 100–240 VAC, 50–60 Hz

• Power Consumption: 190 VA (max at start-up), 115 VA (nominal)

• Dimensions: 429 x 179 x 638 mm

• Weight: 17.8 kg

• Data Logging: Removable flash memory stores approximately 10 years of data

• Connectivity: RS232, USB, Bluetooth, analog and digital I/O, optional TCP/IP

• Certifications:

  • U.S. EPA RFCA–0509–174

  • EN 14625:2013

  • AS 3580.7.1-2011

  • Russian approval 56262-14

Applications

The Serinus 30 is suitable for various applications, including:

• Ambient Air Quality Monitoring: Assessing CO levels in urban and industrial environments.

• Regulatory Compliance: Ensuring adherence to environmental standards.

• Industrial Hygiene: Monitoring workplace air quality.

• Indoor Air Quality: Evaluating CO concentrations in enclosed spaces.

• Environmental Research: Studying pollutant dispersion and atmospheric conditions.

Optional Accessories

• Bluetooth Connectivity: For remote operation via the 'Serinus® Remote' Android app.

• Dual Sample (Particulate) Filter: Enhances sample purity.

• High-Pressure Calibration Options: For direct cylinder calibration.

• Internal DC Pump: Long-life, low power, minimal maintenance.

• 19” Rack Mount Kit: For integration into standard racks.

• External Pump: 240 or 110 VAC options.

• Annual Maintenance Kit: Includes essential components for upkeep.
